SPECTRA DG613 Red Beam Pipe Laser

BIG PERFORMANCE FROM A SMALL DEVICE.

Compact and Powerful, theDG613G extra-bright green beam laser combines great performance with productivity. Advanced functions are user-friendly and allow for easy, fast set-up.

THE BENEFITS JUST KEEP COMING.

The length of the DG613G has been reduced to make it easier to set up the lasers into tight inverts in the manhole. It has a grade range from -12% to +40% and is fully self-leveling over the entire grade range. Even the cross axis is fully compensated providing quick set up and peace of mind that the laser will be level without having to adjust at the bottom of the invert.The DG613G with green beam allows work over a distance of 150m (500ft) even in brighter conditions providing full operation in a single set-up between manholes.

• GRADE RANGE-12% to +40%.
• ULTRA-FAST BEAM movement.
• OPERATING RANGE up to 150 m (500 ft)withradio / IR remote control.
• LARGE INTUITIVE GRAPHICAL DISPLAY on the laser and remote control.
• IP68 PROTECTION (dust and waterproof).
• FLEXIBLE POWER OPTIONS (NiMH / Alkaline).
• ADVANCED FUNCTIONS squeezing working time: Line Set/Check (first day setup), Line Scan (second day setup) and Line Alert.
• AUTOMATIC FUNCTIONS for beam alignment, beam detection, and grade calculation (DG813 only).
• COMPACT LENGTH allows easy set-up even in tight inverts.
• SELF-LEVELING range of -12% to +40% over the entire grade range.
• CROSS AXIS COMPENSATION provides a quicker more accurate set-up as the laser does not have to be level in the pipe place it in the pipe, it levels, you work.
• BRIGHT VISIBLE BEAM works up to 150 m (500 ft).
• RC803 REMOTE works via radio 130 m (430 ft) “over-the-top” or infrared 150 m (500 ft) through the pipe.

SPECIFICATIONS
